Designed to use a sealed emitter allowing for installation in a wide variety of shielded configurations

Our innovative system designs leverage sealed-emitter technology to deliver the benefits of ebeam to R&D lines, narrow web, or 3D part applications. The Dynamic series connects a full range of ebeam capabilities with creative configuration concepts.

dynamic
wdt_ID Technical Specifications Values
1 Accelerating Voltage 80 to 300 kV
2 Maximum Uniform Beam Width 14.2 in
[360 mm]
4 Maximum Production Speed
[Model and Voltage Dependent]
328 ft/min
[100 m/min]
6 Maximum Surface Dose Rate for 80 kV 3 Mrad @ 328 ft/min
[30 kGy @ 100 m/min]
8 Cross-web Uniformity ≤ ±10.0% variation
9 Nitrogen Inerting Level ≤ 200 ppm O2
10 Product Clearance Various
12 Product Support Patented integrated shield roll, beam absorber, or other
13 Potential Dimensions (H x W x D) 19 x 48 x 26 in
[48 x 122 x 66 cm]
15 Facility Requirements Electricity, cooling water, and nitrogen
